Product number: ZYT021352
Back to page
HR swivel hoist rings
● According with EU EN1677 standard .
● Safety factor is 4:1
● Adopt High Strength Alloy Steel.
● Provide customized lengthening screw.





ITEM No. WLL Size( mm) Torque Weight
T L A B C D F K M H S Nm kg
HR125-M8×1.25 0.5 12 48.5 37 76 14 103.5 49.5 8 40 8 30 0.8
HR125-M10×1.5 0.7 16 48.5 37 76 14 103.5 49.5 10 40 8 60 0.8
HR125-M12×1.75 1 18 48.5 37 76 14 103.5 49.5 12 40 8 100 0.8
HR125-M14×2.0 1.5 21 48.5 37 76 14 103.5 49.5 14 40 8 120 0.8
HR125-M16×2.0 2 24 48.5 37 76 14 103.5 49.5 16 40 8 150 0.8
HR125-M20×2.5 3 40 73 54 106 20 151 77 20 54 12 250 2
HR125-M24×3.0 4.5 40 73 54 106 20 151 77 24 54 12 400 2.5
HR125-M30×3.5 7.3 45 98.5 74 149 30 206.5 103.5 30 73 17 500 5.5
HR125-M33×3.5 8 50 98.5 74 149 30 206.5 103.5 33 73 17 800 5.5
HR125-M36×4.0 10 54 98.5 74 149 30 206.5 103.5 36 73 17 1000 5.5
HR125-M39×4.0 10 58 98.5 74 149 30 206.5 103.5 39 73 17 1200 6
HR125-M42×4.5 12.5 63 98.5 74 149 30 206.5 103.5 42 73 17 1500 6
HR125-M48×5.0 20 68 117.5 93 183 36 255 122 48 93 19 2000 11.5
HR125-M52×5.0 20 68 117.5 93 183 36 255 122 52 93 19 2000 12
HR125-M56×5.5 25 78 117.5 93 183 36 255 122 56 93 19 2100 12
HR125-M64×6.0 32 90 117.5 93 183 36 255 122 64 93 19 2200 13
