●Forged with super alloy steel，quenched and tempered.
●It has the characteristics of small size, light weight and high strength.
● Every shackle body has the rated load and model identification.
●Shackle body-surface finish:hot dip galvanizing or electro-galvanized.
●The maximum proof load is 2 times that of the working load limit, and the ultimate load is 4 times that of the working load limit.
●Provide 6:1 the high strength shackle according to requirements.
●Manufactured  in accordance with RR-C-271D and ISO2415-2004.




S6  Grade

ITEM NO.	WLL(t)	SIZE（mm）							Weight( kg/pce)
		W	D	A	B	E	G	H
S-BW0.5-1/4	0.5	11.9	7.9	28.7	6.4	19.8	15.5	46.7	0.05
S-BW0.75-5/16	0.75	13.5	9.7	31.0	7.9	21.3	19.1	53.1	0.10
S-BW1-3/8	1	16.8	11.2	36.6	9.7	26.2	23.1	63.2	0.15
S-BW1.5-7/16	1.5	19.1	12.7	42.9	11.2	29.5	26.9	73.9	0.22
S-BW2-1/2	2	20.6	16.0	47.8	12.7	33.3	30.2	83.3	0.36
S-BW3.25-5/8	3.25	26.9	19.1	60.5	16.0	42.9	38.1	106.4	0.76
S-BW4.75-3/4	4.75	31.8	22.4	71.4	19.1	50.8	46.0	126.2	1.23
S-BW6.5-7/8	6.5	36.6	25.4	84.1	22.4	57.9	53.1	148.1	1.79
S-BW8.5-1	8.5	42.9	28.7	95.3	25.4	68.3	60.5	166.6	2.57
S-BW9.5-1 1/8	9.5	45.0	31.8	108.0	28.7	73.9	68.3	189.7	3.75
S-BW12-1 1/4	12	51.6	35.1	119.1	31.8	82.6	76.2	209.6	5.31
S-BW13.5-1 3/8	13.5	57.2	38.1	133.4	35.1	92.2	84.1	232.7	7.18
S-BW17-1 1/2	17	60.5	41.4	146.1	38.1	98.6	92.2	254.0	9.43
S-BW25-1 3/4	25	73.2	50.8	177.8	44.5	127	106.4	313.4	15.38
S-BW35-2	35	82.6	57.2	196.9	50.8	146.1	122.2	347.5	23.70
S-BW55-2 1/2	55	104.9	70.0	266.7	66.5	184.2	144.5	453.1	44.57

T8 Grade
●Compared with the same size of S6 Strength improvement  40%~100%.
●More lightweight and durable.
●It is suitable for space limited occasions.

ITEM NO.	WLL(t)	SIZE（mm）							Weight( kg/pce)
		W	D	A	B	E	G	H
T-BW2-3/8	2	16.8	11.2	36.6	9.7	26.2	23.1	63.2	0.15
T-BW2.6-7/16	2.6	19.1	12.7	42.9	11.2	29.5	26.9	73.9	0.22
T-BW3.3-1/2	3.3	20.6	16.0	47.8	12.7	33.3	30.2	83.3	0.36
T-BW5-5/8	5	26.9	19.1	60.5	16.0	42.9	38.1	106.4	0.76
T-BW7-3/4	7	31.8	22.4	71.4	19.1	50.8	46.0	126.2	1.23
T-BW9.5-7/8	9.5	36.6	25.4	84.1	22.4	57.9	53.1	148.1	1.79
T-BW12.5-1	12.5	42.9	28.7	95.3	25.4	68.3	60.5	166.6	2.57
T-BW15-1 1/8	15	45.0	31.8	108.0	28.7	73.9	68.3	189.7	3.75
T-BW18-1 1/4	18	51.6	35.1	119.1	31.8	82.6	76.2	209.6	5.31
T-BW21-1 3/8	21	57.2	38.1	133.4	35.1	92.2	84.1	232.7	7.18
T-BW30-1 1/2	30	60.5	41.4	146.1	38.1	98.6	92.2	254.0	9.43
T-BW40-1 3/4	40	73.2	50.8	177.8	44.5	127	106.4	313.4	15.38
T-BW55-2	55	82.6	57.2	196.9	50.8	146.1	122.2	347.5	23.70
T-BW85-2 1/2	85	104.9	70.0	266.7	66.5	184.2	144.5	453.1	44.57
