●Forged with super alloy steel，quenched and tempered.
●It has the characteristics of small size, light weight and high strength.
● Every shakcle body has the rated load and model identification.
●Shackle body-surface finish:hot dip galvanizing or electro-galvanized.
●The maximum proof load is 2 times that of the working load limit, and the ultimate load is 4 times that of the working load limit.
●Provide 6:1 the high strength shackle according to requirements.
●Manufactured  in accordance with RR-C-271D and ISO2415-2004.




S6  Grade

ITEM NO.	WLL(t)	SIZE（mm）						Weight( kg/pce)
		W	D	A	B	G	H
S-DW0.5-1/4	0.5	11.9	7.9	19.1	6.4	15.5	40.4	0.06
S-DW0.75-5/16	0.75	13.5	9.7	25.4	7.9	19.1	48.5	0.10
S-DW1-3/8	1	16.8	11.2	31	9.7	23.1	58.4	0.13
S-DW1.5-7/16	1.5	19.1	12.7	36.1	11.2	26.9	67.6	0.21
S-DW2-1/2	2	20.6	16.0	41.4	12.7	30.2	77	0.28
S-DW3.25-5/8	3.25	26.9	19.1	50.8	16.0	38.1	95.3	0.6
S-DW4.75-3/4	4.75	31.8	22.4	60.5	19.1	46.0	115.1	1.04
S-DW6.5-7/8	6.5	36.6	25.4	71.4	22.4	53.1	135.4	1.63
S-DW8.5-1	8.5	42.9	28.7	81	25.4	60.5	150.6	2.38
S-DW9.5-1 1/8	9.5	45.0	31.8	90.9	28.7	68.3	172.2	3.59
S-DW12-1 1/4	12	51.6	35.1	100	31.8	76.2	190.5	4.65
S-DW13.5-1 3/8	13.5	57.2	38.1	111.3	35.1	84.1	210.3	6.71
S-DW17-1 1/2	17	60.5	41.4	122.2	38.1	92.2	230.1	8.05
S-DW25-1 3/4	25	73.2	50.8	146.1	44.5	106.4	278.6	13.18
S-DW35-2	35	82.6	57.2	171.5	50.8	122.2	311.9	19.3
S-DW55-2 1/2	55	104.9	70.0	203.2	66.5	144.5	377	37.22

T8 Grade
●Compared with the same size of S6 2T~80T Strength improvement  40%~100%, 110T Strength improvement  29%.
●More lightweight and durable.
●It is suitable for space limited occasions.

ITEM NO.	WLL(t)	SIZE（mm）						Weight( kg/pce)
		W	D	A	B	G	H
T-DW2-3/8	2	16.8	11.2	31	9.7	23.1	58.4	0.13
T-DW2.6-7/16	2.6	19.1	12.7	36.1	11.2	26.9	67.6	0.21
T-DW3.3-1/2	3.3	20.6	16.0	41.4	12.7	30.2	77	0.28
T-DW5-5/8	5	26.9	19.1	50.8	16.0	38.1	95.3	0.6
T-DW7-3/4	7	31.8	22.4	60.5	19.1	46.0	115.1	1.04
T-DW9.5-7/8	9.5	36.6	25.4	71.4	22.4	53.1	135.4	1.63
T-DW12.5-1	12.5	42.9	28.7	81	25.4	60.5	150.6	2.38
T-DW15-1 1/8	15	45.0	31.8	90.9	28.7	68.3	172.2	3.59
T-DW18-1 1/4	18	51.6	35.1	100	31.8	76.2	190.5	4.65
T-DW21-1 3/8	21	57.2	38.1	111.3	35.1	84.1	210.3	6.71
T-DW30-1 1/2	30	60.5	41.4	122.2	38.1	92.2	230.1	8.05
T-DW40-1 3/4	40	73.2	50.8	146.1	44.5	106.4	278.6	13.18
T-DW55-2	55	82.6	57.2	171.5	50.8	122.2	311.9	19.3
T-DW85-2 1/2	85	104.9	70.0	203.2	66.5	144.5	377	37.22
